Reliable/ Stable/ Smart/ Safe

SUNT-10.0kW-S | Single Phase | 2 MPPT | IP65

The SUNT-10.0kW-S Hybrid Inverter ensures top-tier performance for both residential and commercial solar installations, offering exceptional protection against dust and water with an IP65 rating. It is compatible with both LiFePO4 and lead-acid batteries, providing versatility in energy storage. With dual MPPTs (Maximum Power Point Tracking), the inverter guarantees optimal energy capture under varying sunlight conditions. The integrated current transformer boosts system performance, while the generator feature ensures continuous operation in the absence of grid power. The inverter is compatible with 220V, 230V, and 240V electrical grids, providing flexibility for different configurations. Integration with the Light Earth mobile platform enables seamless remote monitoring and control via Bluetooth or Wi-Fi, empowering operators and installers to optimize energy flow and system performance for maximum efficiency.

Model: SUNT-10.0kW-S
Max Output Power: 10000W
Rated Output Voltage: 220V/230V/240V
Battery Input Range: 40-60V
MPPT Voltage Range: 120-450V
Max Output Current: 47A
Output Type: Single Phase
Operating Temperature: -25°C~60°C


SUNT-10.0kW-S | Single Phase | 2 MPPT | IP65
  • 75cm² Large Touchscreen Display
  • 240A Max Discharge Current
  • Dual MPPT (120-450V)
  • AC Couple with Micro/String Inverter
  • IP65: Dustproof and Waterproof
  • Compatible with Diesel Generator
  • Built-in Logger with Monitor and Control
  • Sell Surplus Back to the Grid
Advantage
  • Power Limit Function

    1. Easy to install and easy to operate
    2. Multiple intelligent protection to ensure safe use

  • Built-in WIFI and bluetooth

    Connect to a specially designed 'Light Earth' APP via a built-in WIFI logger or Bluetooth connection to perform easy remote monitoring and controlling of the unit.

  • Low power consumption

    Most of the parts in the small grid tie inverter are digital ICs and low-power MCU, which made power consumption.
